型号 model |
YHT-528 |
|
应用 Application |
料斗秤 Hopper scale |
|
量程 Capacity(t) |
0.5t 1t 2t 3t |
|
输出灵敏度 Output sensitivity(mV/V) |
2.0±0.004 |
|
非线性 Nonlinearity(%FS) |
0.02 |
|
重复性 Repeatability(%FS) |
0.02 |
|
迟蒂 Hysteresis(%FS) |
0.02 |
|
蠕变 Creep(%FS/30min) |
0.02 |
|
温度灵敏零点漂移 Temperature effect on sensitivity |
0.02 |
|
温度零点漂移 Temperature effect on zero |
0.02 |
|
零点平衡 Zero balance |
±1.0 |
|
输入阻抗 input resistance |
365±10 |
|
输出阻抗 output resistance |
350±3 |
|
绝缘电阻 insulation resistance |
5000 |
|
推荐极力电压 Recommended excitation voltage |
12 |
|
最大极力电压 Maximum excitation voltage |
15 |
|
温度补偿范围 Compensated temperature range |
-10～+55 |
|
工作补偿范围 Operating temperature range |
-20～+80 |
|
安全超载 Safe Overload |
150 |
|
极限范围 Ultimate Overload |
200 |
|
保护等级 Protection class |
Ip67 |
|
传感器材料 Load cell material |
|
|
合金钢 Alloy steel |
|
|
接线电缆 Connecting |
5.7X6m |
|
接线方式 Method of connecting wire |
红输入(+)黑输入（-） 绿信号（+）白信号（-） |
